Description
The Falcon T501BD A 626 is an extra heavy-duty Grade 1 cylindrical lock engineered for high-traffic and heavy-abuse institutional applications. Non-handed design with removable cylinder for quick re-keying makes retrofitting existing buildings straightforward. Compression spring construction exceeds ANSI/BHMA Grade 1 testing requirements, delivering durability and reliability at solid value.
Standard 2-3/4" backset, 1-3/4" to 2-1/8" door thickness; thin door and extended backset options available. Brass and zinc-plated steel construction with stainless steel springs resist rust. Interchangeable core cylinders (SFIC and large format) supported. Contact an authorized E.D. Locks specialist at sales@edlocks.com or 1-877-207-6067 for detailed specification needs, handing confirmation, and expert installation guidance.
Specifications
- Grade: ANSI/BHMA Grade 1
- Door Thickness: 1-3/4" to 2-1/8" standard
- Backset: 2-3/4" standard; 2-3/8" available
- Bolt Projection: 9/16" standard
- Cylinders: 6-pin chambers, pinned in 5 (6 or 7-pin available)
- Keyway: G (conventional); A (I/C core)
- Cylinder Housing: Solid brass with phosphor bronze springs
- Trim: Heavy wrought brass or bronze roses over cast inserts; pressure cast levers
- Latch Faceplate: 2-1/4" x 1-1/8" with square corners
- Strike: 4-7/8" x 1-1/4" ANSI curved lip
- Material: Brass and cold formed steel (zinc plated, dichromated)
- Springs: Stainless steel and phosphor bronze
- Handing: Non-handed
- Keys: Two nickel silver keys standard
- Interchangeable Core: SFIC and large format available
