Description
The Falcon T561HD D 605 is an extra heavy-duty Grade 1 cylindrical lock engineered for high-traffic and heavy-abuse institutional applications. Built with a compression spring that exceeds ANSI/BHMA Grade 1 testing requirements, this lock delivers reliable security and durability at a solid price point for facilities demanding long-lasting performance.
This lock accepts any manufacturer's cylinder and features easy removal for quick re-keying, simplifying retrofits in existing buildings. Cylinders are drilled with 6-pin chambers pinned in 5, with 6 or 7-pin options available. For compatibility questions, custom backset needs, or interchangeable core options, contact our authorized dealer specialists at sales@edlocks.com or 1-877-207-6067.
Specifications
- Grade: ANSI/BHMA Grade 1
- Door Thickness: 1-3/8" to 2-1/8" standard (thin door adapter kit A30775-000-00 available)
- Backset: 2-3/4" standard (2-3/8" also available; 5" backset link A22161-005-10 available)
- Mechanism: Brass or cold formed steel, zinc plated and dichromated; stainless steel springs
- Attachment: Through-bolted with (2) 10-32 screws
- Handing: Non-handed
- Cylinders: 6-pin chambers pinned in 5; 6 or 7-pin options available; removable for re-keying
- Keyways: "G" keyway standard on conventional cylinders; "A" keyway standard on I/C core cylinders
- Cylinder Housing: Machined solid brass with phosphor bronze springs
- Keys: Two nickel silver keys furnished standard
- Trim: Heavy wrought brass or bronze roses with pressure cast inserts; pressure cast solid levers
- Latch Bolt: 9/16" projection standard, UL listed with 2-1/4" x 1-1/8" faceplates with square corners
- Strike: 4-7/8" x 1-1/4" ANSI strike with curved lip
- Interchangeable Core: Available in small format (SFIC) and large format
