Description
The Falcon TP55E D 613 is a heavy-duty mortise lock built for commercial environments including offices, hospitals, and educational facilities. Featuring a two-piece stainless steel latch bolt and 1-inch dead bolt with saw-resistant rollers, it delivers dependable security and performance even under constant use without fail.
This lock accommodates doors 1-3/8" to 2-1/2" thick with a 2-3/4" backset and supports SFIC interchangeable cores for quick re-keying. Meets ANSI/BHMA 156.13 Series 1000 and carries a 3-hour UL A label. Contact our security experts at sales@edlocks.com or 1-877-207-6067 for installation guidance and authorized dealer support.
Specifications
- Door Thickness: 1-3/8" to 2-1/2"
- Backset: 2-3/4"
- Case: Cold formed steel, zinc dichromate plated, 0.090" thick
- Hubs: Hardened steel
- Handing: Right hand standard; left hand optional, reversible in field
- Cylinders: Solid brass, 5, 6, or 7-pin standard; 6 or 7-pin IC available
- Keyways: "G" standard (standard cylinder); "A" standard (IC cylinder)
- Latch Bolt: Two-piece stainless steel, 3/4" projection
- Dead Bolt: 1" throw, stainless steel with 13/16" hardened steel rollers
- Faceplates: 1-1/4" x 8" brass or stainless steel, adjustable for bevel
- Electrified: 12 or 24 VDC available
- Standards: ANSI/BHMA 156.13 Series 1000, UL 3-hour A label, ANSI A115.1 strike
