Description
The Falcon TP60C A 605 is a mortise lock built for high-traffic commercial environments including offices, hospitals, and educational facilities. This MA Series lock combines dependable security with interchangeable core technology, allowing quick re-keying without removing the lock body. Its two-piece stainless steel latch and roller-bearing deadbolt resist tampering and wear.
The TP60C A 605 fits standard door thicknesses from 1-3/8" to 2-1/2" and works with SFIC interchangeable cores from other manufacturers. It ships with two nickel silver keys and reversible handing for flexible installation. As an authorized Falcon dealer, E.D. Locks offers expert guidance on keying, finish selection, and electrified options. Contact our sales team at sales@edlocks.com or 1-877-207-6067 for compatibility questions.
Specifications
- Brand: Falcon (Allegion)
- Model: TP60C A 605
- Door Thickness: 1-3/8" to 2-1/2"
- Backset: 2-3/4"
- Case Material: Cold formed steel, zinc dichromate plated, 0.090" thick
- Latch Bolt: Two-piece stainless steel, 3/4" projection
- Deadbolt: 1" throw, stainless steel with hardened steel rollers
- Faceplate: 1-1/4" x 8" brass or stainless steel
- Keyways: "G" (standard) or "A" (interchangeable core)
- Cylinders: 5, 6, or 7-pin available
- Handing: Right hand standard, left hand optional, reversible
- Keys Furnished: Two nickel silver keys
- Electrified: 12 or 24 VDC available
- Standards: ANSI/BHMA 156.13 Series 1000, UL 3 hour A label
