Description
The Falcon TP60C A 606 is a commercial mortise lock engineered for high-traffic office, hospital, and education environments. This MA Series lock combines dependable security with interchangeable core technology for easy re-keying, eliminating downtime and simplifying maintenance across your facility.
The TP60C A 606 accommodates standard door thicknesses of 1-3/8" to 2-1/2" with a 2-3/4" backset and meets ANSI/BHMA Series 1000 standards. It accepts SFIC interchangeable cores compatible with other manufacturers' products. Contact E.D. Locks at sales@edlocks.com or 1-877-207-6067 for expert guidance on keying, handing options, and electrified configurations to match your security needs.
Specifications
- Brand: Falcon
- Model: TP60C A 606
- Door Thickness: 1-3/8" to 2-1/2"
- Backset: 2-3/4"
- Case: Cold formed steel, zinc dichromate plated, 0.090" thick
- Latch Bolt: Two-piece stainless steel, 3/4" projection
- Dead Bolt: 1" throw stainless steel with saw-resistant rollers
- Cylinders: Solid brass, 5, 6, or 7-pin standard; 6 or 7-pin interchangeable core
- Standard Keyway: G keyway (standard cylinder), A keyway (interchangeable core)
- Keys: Two nickel silver keys furnished standard
- Handing: Right hand standard; left hand optional, reversible in field
- Faceplate: 1-1/4" x 8" brass or stainless steel, adjustable for door bevel
- Electrified: Available 12 or 24 VDC
- Standards: ANSI/BHMA 156.13 Series 1000, UL 3 hour A label
