Description
The Falcon TP60C Q 625 is a mortise lock engineered for high-traffic commercial environments including offices, hospitals, and educational facilities. This MA Series lock combines dependable security with durability to withstand constant use. Its interchangeable core design enables quick re-keying without removing the lock body, making maintenance straightforward and cost-effective for facility managers.
The lock accommodates standard door thicknesses from 1-3/8" to 2-1/2" and features SFIC compatibility for flexibility across your security infrastructure. As an authorized Falcon dealer, E.D. Locks provides expert guidance on handing options, cylinder pins, keyways, and electrified configurations. Contact our team at sales@edlocks.com or 1-877-207-6067 for professional installation support and to verify compatibility with your specific project requirements.
Specifications
- Brand: Falcon
- Model: TP60C Q 625
- Door Thickness: 1-3/8" to 2-1/2"
- Backset: 2-3/4"
- Case: Cold formed steel, zinc dichromate plated, 0.090" thick
- Hubs: Hardened steel
- Latch Bolt: Two-piece stainless steel, 3/4" projection
- Dead Bolt: 1" throw, stainless steel with saw-resistant rollers
- Cylinders: Solid brass, 5/6/7-pin standard or 6/7-pin interchangeable core
- Keyways: "G" standard cylinder, "A" interchangeable core
- Faceplates: 1-1/4" x 8" brass or stainless steel, armored
- Electrified: 12 or 24 VDC available
- ANSI/BHMA: 156.13, Series 1000
- UL: 3 hour A label
