Description
The Falcon TP60C A 625 is a heavy-duty mortise lock engineered for high-traffic commercial environments including offices, hospitals, and educational facilities. This ANSI/BHMA Series 1000 lock combines a mechanical anti-friction latch bolt with a saw-resistant deadbolt, delivering reliable security and durability for constant daily use without compromise.
The interchangeable core (SFIC) design enables quick field re-keying and works with cylinders from other manufacturers. Fits standard 1-3/8" to 2-1/2" door thickness with 2-3/4" backset. As an authorized Falcon dealer, E.D. Locks provides expert guidance on handing, keying options, and electrified configurations. Contact sales@edlocks.com or 1-877-207-6067 for personalized support.
Specifications
- Door Thickness: 1-3/8" to 2-1/2"
- Backset: 2-3/4"
- Case: Cold formed steel, zinc dichromate plated, 0.090" thick
- Latch Bolt: Two-piece stainless steel, 3/4" projection
- Deadbolt: 1" throw with saw-resistant rollers
- Faceplates: 1-1/4" x 8" brass or stainless steel
- Cylinders: 5, 6, or 7-pin standard; 6 or 7-pin I/C
- Keyways: G (standard), A (I/C)
- Electrified: 12 or 24 VDC available
- Rating: ANSI/BHMA 156.13 Series 1000, UL 3-hour A label
- Handing: Right hand standard, left hand optional, field reversible
