Description
The Falcon TP70T S 626 is a mortise lock built for high-traffic commercial environments including offices, hospitals, and educational facilities. This MA Series lock combines security with durability, featuring a two-piece stainless steel latch bolt, a 1-inch throw dead bolt with saw-resistant rollers, and an interchangeable core for quick re-keying without removing the lock body.
The TP70T S 626 accommodates door thicknesses from 1-3/8" to 2-1/2" with a 2-3/4" backset and meets ANSI/BHMA Series 1000 and 3-hour UL standards. It accepts SFIC interchangeable cores for flexible keying options and is available in electrified versions (12 or 24 VDC). As an authorized Falcon dealer, E.D. Locks provides expert guidance on handing, keyway selection, and installation. Contact sales@edlocks.com or call 1-877-207-6067 for technical support.
Specifications
- Door thickness: 1-3/8" to 2-1/2"
- Backset: 2-3/4"
- Case: Cold formed steel, zinc dichromate plated, 0.090" thick
- Hubs: Hardened steel
- Cylinders: Solid brass, 5, 6, or 7-pin standard; 6 or 7-pin interchangeable core
- Keyways: G keyway standard cylinder; A keyway interchangeable core
- Latch bolt: Two-piece stainless steel, 3/4" projection
- Dead bolt: 1" throw stainless steel with hardened steel rollers
- Faceplates: 1-1/4" x 8" brass or stainless steel
- Strike: Brass or stainless steel, ANSI A115.1 compliant
- Handing: Right hand standard; left hand optional, reversible
- Electrified: Available 12 or 24 VDC
- Standards: ANSI/BHMA 156.13 Series 1000; UL 3-hour A label
