Description
The Falcon TP70T S 625 is a heavy-duty mortise lock built for commercial environments including offices, hospitals, and educational facilities. This MA Series lock combines security with reliability, featuring a two-piece stainless steel latch bolt, anti-friction mechanism, and a 1-inch deadbolt with saw-resistant rollers. Ideal for projects demanding dependable performance under constant use.
The lock accommodates door thickness from 1-3/8" to 2-1/2" with a 2-3/4" backset and includes an interchangeable core (SFIC-compatible) for quick re-keying. It meets ANSI/BHMA 156.13 Series 1000 and UL 3-hour A label ratings. As an authorized Falcon dealer, E.D. Locks provides expert guidance on specifications, handing options, and electrified configurations. Contact sales@edlocks.com or call 1-877-207-6067 for personalized assistance.
Specifications
- Brand: Falcon
- Model: TP70T S 625
- Door Thickness: 1-3/8" to 2-1/2"
- Backset: 2-3/4"
- Case: Cold formed steel, zinc dichromate plated, 0.090" thick
- Latch Bolt: Two-piece stainless steel, 3/4" projection
- Deadbolt: 1" throw stainless steel with saw-resistant rollers
- Cylinder: Solid brass, 5, 6, or 7-pin standard; 6 or 7-pin interchangeable core
- Keyways: G keyway (standard cylinder), A keyway (I/C cylinder)
- Faceplates: 1-1/4" x 8" brass or stainless steel, adjustable for bevel
- Handing: Right hand standard, left hand optional, reversible
- Electrified Options: 12 or 24 VDC available
- Certifications: ANSI/BHMA 156.13 Series 1000, UL 3-hour A label
