Description
The Falcon TP75E D 605 is a heavy-duty mortise lock built for high-traffic commercial environments including offices, hospitals, and educational facilities. Its MA Series design combines security with durability, featuring a two-piece stainless steel latch bolt and one-inch throw deadbolt with saw-resistant rollers. The interchangeable core allows quick re-keying without removing the lock body.
This lock accommodates door thicknesses from 1-3/8" to 2-1/2" and features a 2-3/4" backset. It meets ANSI/BHMA 156.13 Series 1000 standards and carries a 3-hour UL A label. Compatible with SFIC products, it's available in electrified versions (12 or 24 VDC). Contact our authorized dealer team at sales@edlocks.com or 1-877-207-6067 for expert guidance on keying options, handing, and finish selection.
Specifications
- Door Thickness: 1-3/8" to 2-1/2"
- Backset: 2-3/4"
- Case: Cold formed steel, zinc dichromate plated, 0.090" thick
- Hubs: Hardened steel
- Cylinders: Solid brass, 5, 6 or 7-pin available (standard); 6 or 7-pin (interchangeable core)
- Latch Bolt: Two-piece stainless steel, 3/4" projection
- Deadbolt: 1" throw, stainless steel with saw-resistant rollers
- Faceplates: 1-1/4" x 8" brass or stainless steel
- Electrified: 12 or 24 VDC available
- Standards: ANSI/BHMA 156.13 Series 1000, UL 3 hour A label
- Handing: Right hand standard, left hand optional, reversible
