Description
The Falcon TP85E A 606 is a commercial mortise lock engineered for offices, hospitals, educational facilities, and high-traffic institutional environments. This MA Series lock combines robust security with reliable performance under constant use, featuring an interchangeable core for fast re-keying and SFIC compatibility across manufacturers.
The TP85E A 606 fits standard door thicknesses of 1-3/8" to 2-1/2" with a 2-3/4" backset and is reversible in the field for flexible installation. As an authorized Falcon dealer, E.D. Locks provides expert guidance on keying options, electrified configurations, and project specifications. Contact us at sales@edlocks.com or 1-877-207-6067 for technical support and fast delivery.
Specifications
- Brand: Falcon
- Model: TP85E A 606
- Door Thickness: 1-3/8" to 2-1/2"
- Backset: 2-3/4"
- Case: Cold formed steel, zinc dichromate plated, 0.090" thick
- Latch Bolt: Two-piece stainless steel, 3/4" projection
- Dead Bolt: 1" throw with saw-resistant rollers
- Cylinders: 5, 6, or 7-pin standard; 6 or 7-pin interchangeable core
- Keyways: G (standard cylinder), A (I/C cylinder)
- Faceplates: 1-1/4" x 8" brass or stainless steel
- Electrified: 12 or 24 VDC available
- Standard: Right hand; left hand optional
- ANSI/BHMA: 156.13, Series 1000
- UL: 3 hour A label
