Description
The Falcon TP85E D 625 is a mortise lock built for high-traffic commercial environments including offices, hospitals, and educational facilities. Its MA Series delivers dependable security and durability with an interchangeable core for quick re-keying, making it ideal for institutions that need reliable access control without constant maintenance headaches.
This lock accommodates standard door thickness of 1-3/8" to 2-1/2" and features a 2-3/4" backset. It is compatible with SFIC products from other manufacturers, simplifying retrofit projects. As an authorized Falcon dealer, E.D. Locks provides expert guidance on installation, keying options, and electrified configurations. Contact our team at sales@edlocks.com or 1-877-207-6067 for personalized assistance.
Specifications
- Door Thickness: 1-3/8" to 2-1/2"
- Backset: 2-3/4" only
- Case: Cold formed steel, zinc dichromate plated, 0.090" thick
- Hubs: Hardened steel
- Handing: Right hand standard; left hand optional, reversible in field
- Cylinders: Solid brass, 5, 6, or 7-pin available on standard cylinders; 6 or 7-pin on interchangeable core
- Latch Bolt: Two-piece stainless steel, 3/4" projection
- Dead Bolt: 1" throw, stainless steel with saw-resistant rollers
- Faceplates: 1-1/4" x 8" brass or stainless steel, adjustable for door bevel
- Electrified Functions: 12 or 24 VDC available
- Standards: ANSI/BHMA 156.13 Series 1000, UL 3 hour A label
