Description
The Falcon TP85E Q 625 is a heavy-duty mortise lock built for commercial environments like offices, hospitals, and educational facilities. Its MA Series design combines security with reliability, featuring an interchangeable core for quick re-keying and compatibility with SFIC products. The mechanical anti-friction latch and saw-resistant roller deadbolt withstand constant daily use without fail.
This lock accommodates standard door thicknesses of 1-3/8 to 2-1/2 inches with a 2-3/4 inch backset and comes right-hand standard, reversible in the field. It meets ANSI/BHMA 156.13 Series 1000 and carries a 3-hour UL A label. Contact our authorized dealer team at sales@edlocks.com or 1-877-207-6067 for expert guidance on keying options, electrified functions, and finish selection.
Specifications
- Door Thickness: 1-3/8 to 2-1/2 inches
- Backset: 2-3/4 inches only
- Case: Cold formed steel, zinc dichromate plated, 0.090 inch thick
- Hubs: Hardened steel
- Handing: Right hand standard; left hand optional, reversible in field
- Cylinders: Solid brass, 5, 6, or 7-pin standard; 6 or 7-pin interchangeable core
- Latch Bolt: Two-piece stainless steel, mechanical anti-friction, 3/4 inch projection
- Deadbolt: 1 inch throw, stainless steel with two 13/16 inch diameter hardened steel, saw-resistant rollers
- Faceplates: 1-1/4 x 8 inches brass or stainless steel, adjustable for door bevel
- Electrified Functions: Available in 12 or 24 VDC
- Standard Keyways: G keyway on standard cylinder; A keyway on I/C cylinder
- ANSI/BHMA: Meets 156.13, Series 1000
- UL: 3 hour A label
- Keys Furnished: Two nickel silver keys standard
