Description
The Falcon TP85E Q 630 is a heavy-duty mortise lock designed for commercial environments including offices, hospitals, and educational facilities. This MA Series lock combines security with reliability, featuring a two-piece stainless steel latch bolt and a 1-inch throw deadbolt with saw-resistant rollers. Built for constant use, it delivers dependable performance at an accessible price point.
Compatible with standard door thicknesses of 1-3/8" to 2-1/2" with a 2-3/4" backset, this lock supports interchangeable cores (SFIC) for fast re-keying and meets ANSI/BHMA 156.13 Series 1000 standards. Available in 12 or 24 VDC electrified functions. As an authorized Falcon dealer, E.D. Locks provides expert guidance on keying options, finishes, and installation. Contact us at sales@edlocks.com or 1-877-207-6067 for personalized assistance.
Specifications
- Door Thickness: 1-3/8" to 2-1/2"
- Backset: 2-3/4"
- Case: Cold formed steel, zinc dichromate plated, 0.090" thick
- Latch Bolt: Two-piece stainless steel, 3/4" projection
- Deadbolt: 1" throw, stainless steel with saw-resistant rollers
- Faceplates: 1-1/4" x 8" brass or stainless steel
- Cylinders: Solid brass, 5, 6, or 7-pin options
- Keys Furnished: Two nickel silver keys standard
- Electrified Functions: 12 or 24 VDC available
- Certifications: ANSI/BHMA 156.13 Series 1000, UL 3-hour A label
