Description
The Falcon TP85E Q 613 is a heavy-duty mortise lock built for high-traffic commercial environments including offices, hospitals, and educational facilities. It features an interchangeable core (SFIC) for quick re-keying, a mechanical anti-friction latch, and a saw-resistant deadbolt with rollers. Designed for constant use without fail.
Compatible with standard door thicknesses of 1-3/8" to 2-1/2", this lock accommodates 2-3/4" backset and is reversible for right or left hand installation. It meets ANSI/BHMA 156.13 Series 1000 and UL 3-hour A label requirements. Contact our authorized dealer team at sales@edlocks.com or 1-877-207-6067 for expert assistance with keying, handing, or electrified options.
Specifications
- Door Thickness: 1-3/8" to 2-1/2"
- Backset: 2-3/4"
- Case: Cold formed steel, zinc dichromate plated, 0.090" thick
- Hubs: Hardened steel
- Cylinders: Solid brass, 5, 6, or 7-pin (standard); 6 or 7-pin (interchangeable core)
- Latch Bolt: Two-piece stainless steel, 3/4" projection
- Deadbolt: 1" throw stainless steel with two 13/16" hardened steel rollers
- Faceplates: 1-1/4" x 8" brass or stainless steel, adjustable for door bevel
- Handing: Right hand standard; left hand optional, reversible in field
- Electrified Options: 12 or 24 VDC available
- Standards: ANSI/BHMA 156.13 Series 1000, UL 3-hour A label, ANSI A115.1 strike
- Furnished with: Two nickel silver keys
