Description
The Falcon TP85E S 605 is a heavy-duty mortise lock designed for commercial environments including offices, hospitals, and educational facilities. This MA Series lock combines dependable security with affordability, featuring an interchangeable SFIC core for quick re-keying and field reversibility. Built for constant use in high-traffic applications.
Compatible with standard door thicknesses of 1-3/8" to 2-1/2" and a 2-3/4" backset, this lock installs in mortised doors and supports 5, 6, or 7-pin cylinders. As an authorized Falcon dealer, E.D. Locks provides expert guidance on keying options, electrified versions, and field configuration. Contact sales@edlocks.com or call 1-877-207-6067 for personalized assistance.
Specifications
- Door Thickness: 1-3/8" to 2-1/2"
- Backset: 2-3/4"
- Case: Cold formed steel, zinc dichromate plated, 0.090" thick
- Hubs: Hardened steel
- Cylinders: Solid brass, 5, 6 or 7-pin standard; 6 or 7-pin interchangeable core
- Latch Bolt: Two-piece stainless steel, 3/4" projection
- Dead Bolt: 1" throw, stainless steel with saw-resistant rollers
- Faceplates: 1-1/4" x 8" brass or stainless steel, adjustable for door bevel
- Handing: Right hand standard; left hand optional, reversible in field
- Electrified Functions: 12 or 24 VDC available
- ANSI/BHMA: Series 1000
- UL: 3 hour A label
