Description
The Falcon TP95E A 613 is a heavy-duty mortise lock designed for commercial environments including offices, hospitals, and educational facilities. This MA Series lock combines robust security with dependable performance built to withstand constant daily use. It features an interchangeable core for quick re-keying and is compatible with SFIC products from other manufacturers.
The lock accommodates door thickness from 1-3/8" to 2-1/2" with a 2-3/4" backset and includes a 1" throw dead bolt with saw-resistant rollers and a 3/4" latch bolt projection. It meets ANSI/BHMA 156.13 Series 1000 and carries a 3-hour UL A label. Contact our authorized dealer team at sales@edlocks.com or 1-877-207-6067 for expert guidance on handing options, keying configurations, and finish selections.
Specifications
- Brand: Falcon (Allegion)
- Model: TP95E A 613
- Door Thickness: 1-3/8" to 2-1/2"
- Backset: 2-3/4"
- Case: Cold formed steel, zinc dichromate plated, 0.090" thick
- Latch Bolt: Two-piece stainless steel, 3/4" projection
- Dead Bolt: 1" throw stainless steel with hardened steel rollers
- Cylinders: Solid brass, 5, 6, or 7-pin available
- Keyways: G keyway (standard cylinder), A keyway (I/C cylinder)
- Hubs: Hardened steel
- Handing: Right hand standard, left hand optional, reversible
- Faceplates: 1-1/4" x 8" brass or stainless steel
- Electrified: Available 12 or 24 VDC
- ANSI/BHMA: 156.13 Series 1000
- UL Rating: 3 hour A label
