Description
The Falcon TP95E Q 630 is a heavy-duty mortise lock built for commercial environments like offices, hospitals, and educational facilities. Featuring a two-piece stainless steel latch bolt with anti-friction design and a 1-inch throw dead bolt with saw-resistant rollers, this lock delivers dependable security and performance under constant use without compromise.
This mortise lock accommodates door thicknesses from 1-3/8" to 2-1/2" with a 2-3/4" backset and features an interchangeable core for quick re-keying compatible with SFIC products. It meets ANSI/BHMA 156.13 Series 1000 and carries a 3-hour UL A label. Contact our authorized dealer team at sales@edlocks.com or 1-877-207-6067 for expert guidance on keying options, electrified configurations, and handing requirements.
Specifications
- Brand: Falcon
- Model: TP95E Q 630
- Door Thickness: 1-3/8" to 2-1/2"
- Backset: 2-3/4"
- Case: Cold formed steel, zinc dichromate plated, 0.090" thick
- Latch Bolt: Two-piece stainless steel, 3/4" projection
- Dead Bolt: 1" throw stainless steel with saw-resistant rollers
- Cylinder Options: 5, 6, or 7-pin standard; 6 or 7-pin interchangeable core
- Keyways: G (standard cylinder) or A (interchangeable core)
- Faceplates: 1-1/4" x 8" brass or stainless steel, adjustable for bevel
- Electrified: Available 12 or 24 VDC
- Standards: ANSI/BHMA 156.13 Series 1000, UL 3-hour A label
- Handing: Right hand standard; left hand and field-reversible options
