Description
The Falcon TP95E A 630 is a commercial mortise lock built for high-traffic office, hospital, and education environments. Its MA Series design combines security with durability, featuring a two-piece stainless steel latch bolt, saw-resistant roller deadbolt with 1-inch throw, and interchangeable core (SFIC) for quick re-keying without removing the lock body.
This lock fits standard door thicknesses of 1-3/8" to 2-1/2" with 2-3/4" backset and meets ANSI/BHMA 156.13 Series 1000 standards plus UL 3-hour A rating. Right-hand standard; left-hand reversible in field. Contact E.D. Locks at sales@edlocks.com or 1-877-207-6067 for keying options, electrified configurations, and expert installation support from an authorized Allegion dealer.
Specifications
- Brand: Falcon
- Model: TP95E A 630
- Door Thickness: 1-3/8" to 2-1/2"
- Backset: 2-3/4"
- Case: Cold formed steel, zinc dichromate plated, 0.090" thick
- Latch Bolt: Two-piece stainless steel, 3/4" projection
- Deadbolt: 1" throw, stainless steel with saw-resistant rollers
- Hubs: Hardened steel
- Cylinders: Solid brass, 5, 6, or 7-pin standard; 6 or 7-pin I/C
- Keyways: G keyway standard; A keyway on I/C cylinder
- Handing: Right hand standard; left hand optional, reversible
- Faceplates: 1-1/4" x 8" brass or stainless steel, bevel adjustable
- ANSI/BHMA: 156.13, Series 1000
- UL Rating: 3 hour A label
- Electrified: 12 or 24 VDC available
