Description
The Securitron TSB-BK-48 is a touch-triggered electronic release bar for magnetically locked doors. A light touch through gloves or clothing activates a sensor that releases the lock instantly, providing safe egress without special knowledge or tools. Ideal for secure facilities, healthcare, or any application requiring hands-free or contactless door release indoors.
The TSB-BK-48 installs on metal, aluminum, or wood frame doors up to 2-1/4" thick using the included through-bolt kit and can be field-cut for non-standard openings to 48". It operates on 12 VDC or 24 VDC (auto-sensing), includes a 16 ft. cable, backup push button, and trailing edge timer. Contact our authorized dealer team at sales@edlocks.com or 1-877-207-6067 for expert installation guidance and system compatibility advice.
Specifications
- Brand: Securitron
- Model: TSB-BK-48
- Max field-cut length: 48 inches
- Door thickness compatibility: up to 2-1/4 inches
- Voltage: Dual 12 VDC / 24 VDC (automatic)
- Cable: 16 ft. 22 AWG 6-conductor with armored door cord
- Relay rating: DPST 2A
- Power consumption: 40 mA at rest; 25 mA releasing
- Includes: Through-bolt kit, backup push button, trailing edge timer
