Description
Yale's 3000 Series J3301 is a commercial-grade surface-mounted door closer designed for high-traffic entrances, offices, and institutional buildings. Its cast aluminum body, adjustable spring sizes 1-6, and rack-and-pinion mechanism deliver reliable closing action with minimal maintenance. Perfect for architects and facility managers seeking durable, dependable door control.
The J3301 accepts regular arm, top jamb, and parallel arm mounting (tri-packed), making it non-handed and adaptable to most door configurations. Independent valves control latch, sweep, and backcheck intensity for precise adjustment. As an authorized Yale dealer, E.D. Locks provides expert sizing assistance and finishing options. Contact our sales team at sales@edlocks.com or 1-877-207-6067 for application guidance and to verify compatibility with your specific door and frame.
Specifications
- Brand: Yale/Accentra
- Series: 3000
- Model: J3301
- Size Range: 1/2-2
- Body Material: Cast aluminum
- Spring Adjustment: Sizes 1-6
- Piston Diameter: 1-1/4 inch (32mm)
- Pinion Journal Diameter: 5/8 inch (16mm)
- Standard Projection: 2-1/8 inch (54mm)
- Design: Rack and pinion
- Valves: Staked, separate independent latch/sweep/backcheck
- Mounting: Tri-packed (regular, top jamb, parallel arm)
- Handed: Non-handed
