Description
The Yale 8800 Series VIR8865FL mortise lock trim pack delivers commercial-grade security for office buildings, retail spaces, and institutional facilities. This ANSI/BHMA Grade 1 certified lock combines a reinforced stainless steel deadbolt with heavy-duty, vandal-resistant trim to protect high-traffic doors against forced entry and daily wear.
The trim pack fits standard 1-3/4" doors and features field-reversible handing for flexible installation on either hand. Compatible with 6-pin brass cylinders (keyed-random, two keys included) and available in 17 finishes to match your décor. As an authorized Yale dealer, E.D. Locks provides expert guidance on specification and keying. Contact sales@edlocks.com or call 1-877-207-6067 for assistance.
Specifications
- ANSI/BHMA Certification: Series 1000, Operational Grade 1
- UL/cUL Fire Rating: Up to 3 hours
- Mechanism: Stainless steel
- Backset: 2-3/4"
- Latchbolt: 3/4" stainless steel throw
- Door Thickness: 1-3/4" standard (up to 3-1/4" available to order)
- Front: Bevel front, free-floating, adjusts 1/8" in 2"
- Cylinders: Brass, 6-pin keyed-random with two keys (7-pin available to order)
- Reversibility: Field reversible handing
- Strike: 1-1/4" curved lip for 1-3/4" doors (other lengths available to order)
- Finishes: 17 options available
- Warranty: 10 years mechanical
