Description
The Yale 8800 Series mortise lock trim pack delivers commercial-grade security for high-traffic doors. Built for uncompromising strength, it features a reinforced stainless steel deadbolt, heavy-duty vandal-resistant trim, and ANSI/BHMA Grade 1 certification. Quick lever handing and field-reversible design simplify installation on doors up to 3-1/4" thick.
This trim pack is compatible with standard 1-3/4" doors and includes a curved lip strike, 6-pin keyed-random cylinder with two keys, and 2-3/4" backset. UL/cUL fire-rated up to 3 hours and windstorm certified. Contact our authorized dealer experts at sales@edlocks.com or 1-877-207-6067 for finish selection, keying assistance, and fast shipping on orders over $450.
Specifications
- ANSI/BHMA Certification: A156.13, Series 1000, Grade 1
- Fire Rating: UL/cUL rated up to 3 hours
- Backset: 2-3/4"
- Latchbolt: 3/4" stainless steel throw
- Door Thickness: 1-3/4" standard (up to 3-1/4" to order)
- Cylinder: Brass, 6-pin keyed-random, 7-pin available
- Strike: 1-1/4" curved lip for 1-3/4" door (other sizes available)
- Handing: Field reversible
- Finishes: 17 available finishes
- Warranty: 10 years mechanical
