Description
The Yale 8832FL 626 Trim Pack is a heavy-duty mortise lock assembly designed for commercial doors requiring maximum security and durability. Built for institutional, corporate, and high-traffic environments, it features a reinforced stainless steel deadbolt, vandal-resistant trim, and ANSI/BHMA Grade 1 certification to withstand years of demanding use.
This trim pack fits standard 1-3/4" doors and installs easily with field-reversible handing and quick lever configuration. As an authorized Yale/Accentra dealer, E.D. Locks offers expert guidance on finish selection, keying, and compatibility. Contact our sales team at sales@edlocks.com or 1-877-207-6067 for application support.
Specifications
- ANSI/BHMA Certification: A156.13, Series 1000, Grade 1
- UL/cUL Fire Rated: Up to 3 hours
- Windstorm Certified: Per local codes
- Backset: 2-3/4"
- Latchbolt: 3/4" stainless steel throw
- Door Thickness: 1-3/4" standard (up to 3-1/4" available)
- Front: Bevel front, free-floating (flat to 1/8" standard bevel)
- Cylinders: Brass, 6-pin keyed-random with 2 keys (7-pin available)
- Field Reversible: Yes
- Strike: 1-1/4" curved lip for 1-3/4" door (other lengths available)
- Finishes: 17 options available
- Warranty: 10 years mechanical
