Description
The Yale 8862FL 626 Trim Pack is a commercial-grade mortise lock designed for doors requiring ANSI/BHMA Grade 1 security and durability. Built with reinforced stainless steel components and heavy-duty vandal-resistant trim, this lock suits office buildings, retail spaces, and institutional facilities where reliable access control and long-term performance are essential.
The 8862FL features field-reversible handing, a 2-3/4 inch backrest, and a 3/4 inch stainless steel latchbolt suitable for standard 1-3/4 inch doors. UL/cUL fire-rated up to 3 hours and backed by a 10-year mechanical warranty. As an authorized Yale dealer, E.D. Locks offers expert consultation and fast shipping on all Grade 1 mortise locks. Contact sales@edlocks.com or call 1-877-207-6067 for specification verification and project support.
Specifications
- Brand: Yale/Accentra
- Model: VIR8862FL 626
- ANSI/BHMA Certification: A156.13, Series 1000, Grade 1
- UL/cUL Rating: Fire-rated up to 3 hours
- Backset: 2-3/4 inch
- Latchbolt: 3/4 inch stainless steel throw
- Door Thickness: 1-3/4 inch standard; up to 3-1/4 inch available to order
- Mechanism: Stainless steel
- Cylinders: Brass, 6-pin keyed-random with two keys standard; 7-pin available to order
- Strikes: 1-1/4 inch curved lip for 1-3/4 inch door standard; reversible
- Front: Bevel front, free-floating to adjust from flat to 1/8 inch standard bevel
- Reversibility: Field reversible handing
- Finishes: Available in 17 finishes per Yale Commercial Finishes Chart
- Warranty: 10 year mechanical
- Windstorm: Certified per local codes
