Description
The Sargent 80 Series exit device is a heavy-duty panic bar system designed for commercial facilities requiring ANSI/BHMA Grade 1 certified security. Built for wood and metal doors 1-3/4" thick, this rim-mounted, right-hand reverse (RHR) configuration provides exceptional durability with modular construction and minimal moving parts, making it ideal for high-traffic buildings where reliability is non-negotiable.
This exit device fits E-rail doors 24-32" wide without cutting for 32" doors. Installation requires a minimum 4-1/2" stile width and is compatible with standard panic hardware mounting. As an authorized Sargent dealer, E.D. Locks offers expert guidance on configuration, keying, and compliance questions. Contact our sales team at sales@edlocks.com or 1-877-207-6067 for fast, knowledgeable support on your installation.
Specifications
- Brand: Sargent
- Model: 194356-8343E
- Configuration: RHR BSP (Rim, Right-Hand Reverse, Except Pushpad)
- Door Thickness: 1-3/4" (44mm)
- Door Width (E Rail): 24" to 32" (61cm to 81cm)
- Minimum Stile Width: 4-1/2" (114mm)
- Grade: ANSI/BHMA Grade 1
- Material Compatibility: Wood or Metal Doors
