Description
The Sargent 6500 is a standard-duty key-in-lever cylindrical lock engineered to meet ANSI A156.2 Series 4000 Grade 2 performance. Ideal for office buildings, retail spaces, and institutional facilities, it provides reliable keyed access control on doors 1-3/8" to 1-3/4" thick with universal hand installation and a 1/2" brass throw latch.
This lock fits standard ANSI A115.2 (161) modified door prep with a 2-3/4" backset (2-3/8" optional). Available in six finishes with choice of strike styles, it ships with two nickel silver keys and a 6-pin brass cylinder in LA keyway. As an authorized Sargent dealer, E.D. Locks offers expert configuration help and fast shipping. Contact sales@edlocks.com or call 1-877-207-6067 for keying options and finish selection.
Specifications
- Brand: Sargent
- Model: 28-65G05 KP 4
- Lock Type: Key-In-Lever Cylindrical
- Door Thickness: 1-3/8" to 1-3/4" (35mm to 44mm)
- Backset: 2-3/4" (70mm) standard; 2-3/8" (60mm) optional
- Latch Throw: 1/2" (13mm) brass
- Cylinder: 6-pin brass, LA keyway
- Keys Included: Two nickel silver
- Front Plate: Wrought brass and stainless steel, 2-1/4" x 1-1/8"
- Strike Options: 600 curved lip (brass or stainless); 808 ANSI curved lip; 505 full lip
- Finishes: 3, 4, 10, 10B, 26, 26D
- Hand: Universal
- ANSI Rating: A156.2 Series 4000 Grade 2
- Door Prep: ANSI A115.2 (161) Modified
- Minimum Stile Width: 4-1/2" (114mm)
