Description
The Sargent 28-7G05 LB is a key-in-lever lock engineered for standard-duty commercial use in public buildings, medical offices, hotels, and government facilities. It exceeds ANSI/BHMA A156.2 standards for cycling and durability, delivering reliable security and smooth operation in high-traffic interior and exterior applications.
This lock accommodates 1-3/4" standard doors (1-3/8" available) with a 2-3/4" backset (2-3/8" optional). Available in multiple finishes and lever designs, it accepts master or grand master keying. For proper sizing, compatibility verification, and keying assistance, contact our authorized dealer team at sales@edlocks.com or 1-877-207-6067.
Specifications
- Brand: Sargent
- Model: 28-7G05 LB 15
- Door Thickness: 1-3/4" (44mm) standard; 1-3/8" (35mm) optional
- Backset: 2-3/4" (70mm) standard; 2-3/8" (60mm) optional
- Latch Throw: 1/2" (13mm)
- Cylinder: 6-pin brass, LA keyway standard
- Housing: Steel, zinc dichromate finish
- Front Plate: 2-1/4" x 1-1/8" (57mm x 29mm) standard
- Strike Options: 2-3/4" curved lip (standard), 4-7/8" curved lip, 2-1/4" full lip
- Lever Designs: B, L, P (non-handed); G, Y (handed)
- Keys Included: Two nickel silver
- Finishes: 03, 04, 09, 10, 10B, 10BE, 10BL, 14, 15, 20D, 26, 26D
- Door Prep: ANSI A115.2 (160 prep optional)
- Standards: Exceeds ANSI/BHMA A156.2
