Description
The LCN 4040XP is a heavy-duty surface-mounted door closer engineered for institutional and high-traffic environments. Its 44% increased bearing load capacity, 3/4" pinion journal diameter, and reinforced steel pinion teeth deliver maximum durability. The enhanced V-shield seal extends seal life by 20%, making this closer ideal for demanding applications where reliability cannot compromise.
This non-handed closer adjusts for interior doors up to 5 feet and exterior doors up to 4 feet, mounting on the hinge side, top jamb, or parallel arm. It meets ADA requirements and is UL and cUL listed to ANSI A156.4 Grade One. As an authorized LCN dealer, E.D. Locks offers expert guidance on finishes, corrosive-environment primers, and compatibility with all 4040 accessories. Contact us at sales@edlocks.com or 1-877-207-6067 for fast, accurate installation support.
Specifications
- Brand: LCN
- Model: 4040XP
- Handing: Left Hand (LH)
- Finish: Aluminum (AL) with Powder Coat
- Bearing Load Capacity: 44% increased over standard
- Pinion Journal Diameter: 3/4"
- Bearing Width: 5/8"
- V-Shield Seal: 20% longer life
- Interior Door Range: Up to 5'0"
- Exterior Door Range: Up to 4'0"
- Mount Options: Hinge side, top jamb, or parallel arm (with PA bracket)
- Certifications: UL and cUL listed, ANSI A156.4 Grade One
- ADA Compliant: Yes
- Material: Cast iron body, forged steel arm, double heat-treated steel pinion
- Fluid: All-weather
- Installation: LCN Fast Power Adjust with fast and accurate setup
