Description
The Arrow AL500-36-630-LR is a microprocessor-based alarmed exit device designed for facilities requiring enhanced security on emergency exits. When armed, it sounds a 103 dB pulsating alarm immediately upon rail depression, with a flashing red LED for visible violation indication. Ideal for retail, healthcare, and institutional settings where exit monitoring is critical.
This UL and cUL listed device operates on 9VDC battery power with low battery alerts and field-selectable continuous alarm or automatic re-arming options. The 36-inch model includes tamper-resistant Guarded Latch and rail monitoring. Installation requires a 1-1/8" mortise cylinder (ordered separately). Contact an authorized E.D. Locks dealer at sales@edlocks.com or 1-877-207-6067 for expert guidance on compatibility, cylinder selection, and keying to ensure proper integration with your door system.
Specifications
- Brand: Arrow
- Model: AL500-36-630-LR
- Device Width: 36 inches
- Alarm Volume: 103 dB @ 8 feet, pulsating horn
- Power: Battery powered, 9VDC
- Alarm Features: Immediate activation on rail depression when armed; flashing red LED; key-reset indicator
- Field Options: Continuous alarm mode; automatic re-arming
- Security Features: Guarded Latch (tamper-resistant); rail monitoring standard
- Arming/Disarming: Inside cylinder operation with 1-1/8" (29mm) mortise cylinder, 001 cam (cylinder ordered separately)
- Certifications: UL Listed; cUL Listed to Canadian Safety Standards
- Low Battery Alert: Yes
- Minimum Door Width: 36-1/4" to 48" for this model
