Description
The Arrow AL500F-36-630-RR is a microprocessor-based alarmed exit device designed for commercial doors requiring both emergency egress and intrusion detection. When armed, the device immediately triggers a 103 dB pulsating horn alarm upon rail depression, with a flashing red LED for visible violation indication. Ideal for retail, office, and institutional facilities needing to prevent unauthorized door use while maintaining code-compliant emergency exit functionality.
This model fits doors 32.25 to 36 inches wide and includes tamper-resistant latching and field-selectable continuous alarm or automatic re-arming options. Arm or disarm via 1-1/8 inch mortise cylinder (ordered separately). UL and cUL listed. As an authorized Arrow dealer, E.D. Locks provides expert installation guidance and keying support. Contact sales@edlocks.com or 1-877-207-6067 for compatibility verification and technical assistance.
Specifications
- Brand: Arrow
- Model: AL500F-36-630-RR
- Device Type: Alarmed Exit Device
- Alarm Output: 103 dB at 8 feet, pulsating horn
- Power Source: Battery powered, 9VDC
- Visual Indicator: Flashing red LED
- Latch Type: Guarded Latch (tamper resistant)
- Arm/Disarm: Inside cylinder operation with 1-1/8 inch mortise cylinder (29mm), 001 cam
- Door Width Compatibility: 32.25 to 36 inches
- Field Options: Continuous alarm mode, automatic re-arming
- Reset: Key only
- Certifications: UL Listed, cUL Listed, UL Listed to Canadian Safety Standards
- Internal Features: Rail Monitoring and Guarded Latch standard
