Description
The Arrow AL500-36-689-RR is a microprocessor-based alarmed exit device designed for facilities requiring enhanced security and tamper detection. When armed, it sounds an immediate 103 dB alarm upon rail depression, with a flashing red LED for visible violation indication. Ideal for retail, healthcare, and institutional buildings protecting high-risk exits.
This UL and cUL listed device features guarded latch technology, battery backup (9VDC), and field-selectable continuous alarm or automatic re-arming options. It requires a separate 1-1/8" mortise cylinder with 001 cam for arm/disarm control. E.D. Locks is an authorized Arrow dealer offering expert sizing guidance and installation support at sales@edlocks.com or 1-877-207-6067.
Specifications
- Brand: Arrow
- Model: AL500-36-689-RR
- Alarm Volume: 103 dB @ 8 ft pulsating horn
- Power: Battery powered, 9VDC
- LED: Flashing red for violation indication, key reset only
- Features: Microprocessor based, guarded latch, tamper resistant, rail monitoring
- Cylinder: 1-1/8" (29mm) mortise with 001 cam (ordered separately)
- Door Width Compatibility: E 32" only, F 32-1/4 - 36", G 36-1/4 - 48"
- Certifications: UL Listed, cUL Listed to Canadian Safety Standards
- Options: Low battery alert, field selectable continuous alarm, automatic re-arming
