Description
The Arrow AL500-36-630-RR is a microprocessor-based alarmed exit device designed for facilities requiring enhanced emergency egress security. When armed, it triggers a 103 dB pulsating alarm immediately upon rail depression, with a flashing red LED for visual violation indication. Ideal for schools, hospitals, retail, and commercial buildings seeking to prevent unauthorized exits while maintaining code-compliant emergency egress.
This UL and cUL listed device features tamper-resistant guarded latch technology, battery-powered 9VDC operation, and field-selectable continuous alarm or automatic re-arming options. The inside mortise cylinder (1-1/8 inch, sold separately) arms or disarms via key only. Verify your door width falls within the applicable range (E: 32 inch minimum; F: 32.25-36 inch; G: 36.25-48 inch). Contact our authorized dealer experts at sales@edlocks.com or 1-877-207-6067 for proper sizing, keying, and installation guidance.
Specifications
- Brand: Arrow
- Model: AL500-36-630-RR
- Alarm Output: 103 dB at 8 feet, pulsating horn
- Power: 9VDC battery powered
- Visual Alert: Flashing red LED, key reset only
- Internal Features: Rail monitoring, guarded latch (tamper resistant)
- Control: Inside mortise cylinder operation, 1-1/8 inch (29mm), 001 cam
- Certifications: UL listed, cUL listed to Canadian Safety Standards
- Minimum Door Widths: E 32 inch, F 32.25-36 inch, G 36.25-48 inch
- Options: Field-selectable continuous alarm, automatic re-arming, low battery alert
