Description
The Arrow AL500F-48-689-RR is a microprocessor-based alarmed exit device designed for facilities requiring enhanced security on emergency exits. When armed, it triggers a 103 dB pulsating alarm immediately upon rail depression, with a flashing red LED for visual indication. Ideal for hospitals, schools, retail, and offices seeking to prevent unauthorized egress while maintaining life safety compliance.
This UL and cUL listed device features tamper-resistant latching, 9VDC battery operation, and field-selectable continuous alarm or automatic re-arming modes. It accommodates door widths from 32 inches to 48 inches and accepts a 1-1/8 inch mortise cylinder (ordered separately) for key-controlled arming. Contact an E.D. Locks authorized dealer at sales@edlocks.com or 1-877-207-6067 for expert guidance on cylinder selection, installation, and compatibility with your door frame.
Specifications
- Brand: Arrow
- Model: AL500F-48-689-RR
- Alarm Level: 103 dB at 8 feet, pulsating
- Power: 9VDC battery
- Visual Indicator: Flashing red LED, key reset
- Internal Features: Rail monitoring, guarded latch (tamper resistant)
- Cylinder: 1-1/8 inch mortise, 001 cam (ordered separately)
- Door Width Range: E 32 inches; F 32.25-36 inches; G 36.25-48 inches
- Certifications: UL Listed, cUL Listed, UL Listed to Canadian Safety Standards
- Options: Field selectable continuous alarm, automatic re-arming
