Description
The Falcon MA101 QG 613 is a heavy-duty mortise lock built for commercial environments like offices, hospitals, and educational facilities. Its interchangeable core design enables quick re-keying, while the mechanical anti-friction latch and saw-resistant roller deadbolt deliver dependable security and performance under constant daily use.
Compatible with standard 1-3/8" to 2-1/2" door thicknesses and SFIC products from other manufacturers, this lock offers field-reversible handing and meets ANSI/BHMA Series 1000 standards. Contact our authorized dealer experts at sales@edlocks.com or 1-877-207-6067 for keying options, finish selection, and installation guidance.
Specifications
- Brand: Falcon
- Model: MA101 QG 613
- Door Thickness: 1-3/8" to 2-1/2"
- Backset: 2-3/4"
- Latch Bolt: Two-piece stainless steel, 3/4" projection
- Deadbolt: 1" throw, stainless steel with saw-resistant rollers
- Case: Cold formed steel, zinc dichromate plated, 0.090" thick
- Hubs: Hardened steel
- Cylinders: Solid brass, 5/6/7-pin available (standard); 6/7-pin (interchangeable core)
- Keyway: G (standard cylinder), A (interchangeable core)
- Handing: Right hand standard, left hand optional, reversible in field
- Faceplate: 1-1/4" x 8" brass or stainless steel, armored
- Strike: Brass or stainless steel, non-handed, meets ANSI A115.1
- Electrified Functions: 12 or 24 VDC available
- ANSI/BHMA: Series 1000
- UL Rating: 3 hour A label
