Description
The Yale 8800 Series mortise lock trim pack delivers commercial-grade security for interior and exterior doors. Designed for facilities managers and contractors who demand durability, this ANSI/BHMA Grade 1 certified lock features a reinforced stainless steel deadbolt, vandal-resistant trim, and field-reversible handing for flexible installation across multiple door types and thicknesses.
This trim pack fits standard 1-3/4" doors and accommodates thicker doors up to 3-1/4" by special order. The 6-pin brass cylinder comes keyed-random with two keys; a 7-pin option is available. For expert guidance on compatibility with your specific application, keying systems, or finish selection from our 17 available options, contact our authorized dealer team at sales@edlocks.com or 1-877-207-6067.
Specifications
- Certification: ANSI/BHMA A156.13, Series 1000, Operational Grade 1
- Fire Rating: UL/cUL rated up to 3 hours
- Backset: 2-3/4"
- Latchbolt: 3/4" stainless steel throw
- Door Thickness: 1-3/4" standard; to 3-1/4" by special order
- Mechanism: Stainless steel
- Cylinders: 6-pin brass, keyed-random with two keys; 7-pin available to order
- Reversibility: Field reversible handing
- Strike: 1-1/4" curved lip for 1-3/4" door standard; reversible
- Finishes: 17 available options
- Warranty: 10 years mechanical
