Description
The Schlage ND80BD is a Grade 1 cylindrical lockset engineered for commercial facilities including healthcare, education, government, office and retail environments. This non-handed lever lock installs easily on standard doors and delivers proven reliability with a 3-million-cycle rating, ensuring long-term performance in high-traffic applications.
Compatible with doors 1 5/8" to 2 1/8" thick, the ND80BD features a standard 2 3/4" backset and includes a 6-pin Everest 29 keyway with two keys. The lock supports master keying, interchangeable cores, and wireless access control integration. As an authorized Schlage dealer, E.D. Locks provides expert installation guidance and keying assistance. Contact sales@edlocks.com or call 1-877-207-6067 for expert help.
Specifications
- Grade: 1 (ANSI/BHMA certified)
- Operating Cycles: 3 million without failure
- Door Thickness: 1 5/8" to 2 1/8" (41mm-54mm) standard
- Backset: 2 3/4" (70mm) standard; 2 3/8", 3 3/4", 5" optional
- Faceplate: 1 1/8" x 2 1/4", square corner, beveled
- Latch Bolt: Steel, 1/2" throw, deadlocking
- Cylinder: 6-pin Everest 29 S123 keyway
- Keys: Two patented nickel silver keys per lock
- Keying Options: Master keying, grand master keying, construction keying, interchangeable core, Primus high security
- Warranty: Ten-year limited
