Description
The Falcon T411HD is a heavy-duty Grade 1 cylindrical lock engineered for high-traffic institutional and commercial applications. It features a compression spring design that exceeds ANSI/BHMA Grade 1 requirements, brass and stainless steel construction for durability, and removable cylinders for quick re-keying without replacing the entire lock mechanism.
Standard 2-3/4" backset fits 1-3/4" to 2-1/8" door thickness; adapters and alternate backsets are available. The lock accepts most manufacturers' cylinders and interchangeable core designs. Contact an authorized E.D. Locks dealer at sales@edlocks.com or 1-877-207-6067 for expert guidance on specification, keying options, and door preparation to ensure a perfect fit.
Specifications
- Grade: ANSI/BHMA Grade 1
- Door Thickness: 1-3/4" to 2-1/8" standard
- Backset: 2-3/4" standard (2-3/8" available)
- Bolt Projection: 9/16" standard
- Latch Faceplate: 2-1/4" x 1-1/8" (square corners)
- Strike: 4-7/8" x 1-1/4" ANSI curved-lip
- Cylinders: 6-pin standard (5 pinned), 7-pin available, removable
- Keyway: G keyway standard
- Construction: Brass/cold-formed steel (zinc plated), stainless steel springs
- Keys Furnished: Two nickel silver keys standard
- Handing: Non-handed
- Finish: 626
