Description
The Falcon T501BD is an extra heavy-duty Grade 1 cylindrical lock engineered for high-traffic and high-abuse institutional applications. It exceeds ANSI/BHMA Grade 1 testing requirements and features a compression spring design with brass and stainless steel construction for durability and rust resistance. Non-handed design simplifies inventory and installation across your facility.
The T501BD accepts most manufacturer cylinders and allows quick re-keying without lock removal, making retrofits and re-keying simple and cost-effective. Standard 2-3/4" backset fits 1-3/4" to 2-1/8" doors; adapters and alternative backsets are available. Contact E.D. Locks' expert team at sales@edlocks.com or 1-877-207-6067 for compatibility verification, keying assistance, and specification guidance.
Specifications
- Grade: ANSI/BHMA Grade 1
- Door Thickness: 1-3/4" to 2-1/8" standard
- Backset: 2-3/4" standard (2-3/8" and 5" also available)
- Bolt Projection: 9/16" standard (3/4" available)
- Cylinders: 6-pin drilled, pinned in 5 (6 or 7-pin available)
- Keyway: "G" keyway standard ("A" on interchangeable core)
- Latch Faceplate: 2-1/4" x 1-1/8" with square corners
- Material: Brass and cold-formed steel, zinc plated and dichromated
- Springs: Stainless steel and phosphor bronze
- Keys: Two nickel silver keys standard
- Interchangeable Core: Available in small format (SFIC) and large format
- Strike: 4-7/8" x 1-1/4" ANSI strike with curved lip
- Handing: Non-handed
