Description
The Falcon T571HD D 626 is an extra heavy-duty Grade 1 cylindrical lock built for high-traffic institutional and commercial environments where durability is non-negotiable. Its compression spring design exceeds ANSI/BHMA Grade 1 testing requirements, making it ideal for schools, hospitals, government buildings, and other heavy-use facilities demanding reliable security and longevity.
This lock accepts any manufacturer's cylinder and features removable cylinders for quick, tool-free re-keying, simplifying retrofits and facility updates. Available in multiple backsets, door thicknesses, and cylinder options including interchangeable core designs. As an authorized Falcon dealer, E.D. Locks provides expert guidance on configuration, installation, and keying. Contact our sales team at sales@edlocks.com or 1-877-207-6067 for personalized assistance.
Specifications
- Grade: ANSI/BHMA Grade 1
- Door Thickness: 1-3/4" to 2-1/8" standard (thin door adapter kit available)
- Backset: 2-3/4" standard; 2-3/8" also available; 5" available with link
- Bolt Projection: 9/16" standard; 3/4" optional
- Latch Faceplate: 2-1/4" x 1-1/8" (square corners, UL listed)
- Strike: 4-7/8" x 1-1/4" ANSI with curved lip
- Cylinders: Drilled 6-pin, pinned in 5 (6-pin or 7-pin available); removable for re-keying
- Keyway: G standard (conventional); A standard (interchangeable core)
- Cylinder Material: Solid brass housings and plugs with phosphor bronze springs
- Lock Body: Brass or cold formed steel with zinc-plated, dichromated finish; stainless steel springs
- Handing: Non-handed
- Interchangeable Core: Available in small format (SFIC) and large format
- Keys: Two nickel silver keys furnished standard
- Attachment: Through-bolted with (2) 10-32 screws
