Description
The Falcon TP60C D 606 is a mortise lock built for high-traffic commercial environments including offices, hospitals, and educational facilities. This MA Series lock combines dependable security with durability, featuring a mechanical anti-friction latch bolt and a 1-inch throw deadbolt with saw-resistant rollers. It handles constant use without fail.
The lock accommodates doors 1-3/8" to 2-1/2" thick with a 2-3/4" backset and ships with interchangeable core capability for fast re-keying. It meets ANSI/BHMA Series 1000 and carries a 3-hour UL A label. Contact E.D. Locks' expert team at sales@edlocks.com or 1-877-207-6067 for compatibility confirmation and installation guidance on your project.
Specifications
- Brand: Falcon (Allegion)
- Model: TP60C D 606
- Door Thickness: 1-3/8" to 2-1/2"
- Backset: 2-3/4" only
- Case: Cold formed steel, zinc dichromate plated, 0.090" thick
- Latch Bolt: Two-piece stainless steel, 3/4" projection
- Deadbolt: 1" throw, stainless steel with saw-resistant rollers
- Cylinders: Solid brass, 5, 6, or 7-pin standard; 6 or 7-pin interchangeable core
- Keys: Two nickel silver keys standard
- Keyways: G keyway standard cylinder; A keyway I/C cylinder
- Handing: Right hand standard, left hand optional, reversible in field
- Faceplates: 1-1/4" x 8" brass or stainless steel, adjustable for door bevel
- Strike: Brass or stainless steel, non-handed, meets ANSI A115.1
- Electrified: Available 12 or 24 VDC
- Certifications: ANSI/BHMA 156.13 Series 1000, UL 3-hour A label
