Description
The Falcon TP60C S 606 is a commercial mortise lock designed for offices, hospitals, schools, and other institutional facilities requiring reliable, heavy-duty security. Built to withstand constant use, this MA Series lock combines dependable performance with an interchangeable core (SFIC) that allows quick re-keying without removing the lock body, solving the costly downtime problem in multi-tenant or frequently accessed buildings.
The lock accommodates standard door thicknesses from 1-3/8" to 2-1/2" with a 2-3/4" backset and meets ANSI/BHMA 156.13 Series 1000 and UL 3-hour A label standards. Right-hand handing is standard; left-hand and field-reversible options are available. Interchangeable cores are compatible with SFIC cylinders from other manufacturers. Contact our authorized dealer team at sales@edlocks.com or 1-877-207-6067 for expert keying guidance, finish selection, and project support.
Specifications
- Brand: Falcon (Allegion)
- Model: TP60C S 606
- Lock Type: Mortise
- Door Thickness: 1-3/8" to 2-1/2"
- Backset: 2-3/4"
- Case: Cold formed steel, zinc dichromate plated, 0.090" thick
- Hubs: Hardened steel
- Handing: Right hand standard; left hand optional, field reversible
- Latch Bolt: Two-piece stainless steel, mechanical anti-friction, 3/4" projection
- Dead Bolt: 1" throw, stainless steel with saw-resistant rollers
- Cylinder Options: 5, 6, or 7-pin solid brass (standard); 6 or 7-pin interchangeable core
- Keyways: "G" keyway (standard cylinder), "A" keyway (interchangeable core)
- Keys Included: Two nickel silver keys
- Faceplates: 1-1/4" x 8" brass or stainless steel, adjustable for door bevel
- Strike: Brass or stainless steel, non-handed, meets ANSI A115.1
- Electrified Functions: 12 or 24 VDC available
- Standards: ANSI/BHMA 156.13 Series 1000, UL 3-hour A label
