Description
The Falcon TP65E A 626 is a mortise lock engineered for high-traffic commercial environments including offices, hospitals, and educational facilities. Its MA Series delivers dependable security and durability with an interchangeable core (SFIC) that simplifies re-keying without removing the lock body, ideal for buildings that require flexible key management.
This lock accommodates doors 1-3/8" to 2-1/2" thick with a 2-3/4" backset and meets ANSI/BHMA 156.13 Series 1000 standards and UL 3-hour A certification. It features a 1" throw deadbolt with saw-resistant rollers and a 3/4" latch bolt. As an authorized Falcon dealer, E.D. Locks provides expert guidance on finish selection, electrified options (12/24 VDC), and keying configuration. Contact sales@edlocks.com or call 1-877-207-6067 for professional support.
Specifications
- Brand: Falcon
- Model: TP65E A 626
- Lock Type: Mortise
- Door Thickness: 1-3/8" to 2-1/2"
- Backset: 2-3/4"
- Case: Cold formed steel, zinc dichromate plated, 0.090" thick
- Latch Bolt: 3/4" projection, stainless steel
- Deadbolt: 1" throw, stainless steel with hardened steel rollers
- Cylinder: Solid brass, 5/6/7-pin standard or 6/7-pin interchangeable core
- Keyway: G keyway (standard) or A keyway (interchangeable core)
- Handing: Right hand standard, left hand reversible
- Faceplate: 1-1/4" x 8" brass or stainless steel
- Electrified: 12 or 24 VDC available
- Standards: ANSI/BHMA 156.13 Series 1000, UL 3-hour A label
