Description
The Falcon TP65E S 626 is a heavy-duty mortise lock built for commercial environments including offices, hospitals, and educational facilities. Its MA Series design combines security with durability to withstand constant daily use. The interchangeable core (SFIC-compatible) enables quick re-keying without removing the lock body, making maintenance and retrofits straightforward and cost-effective.
This mortise lock accommodates standard door thicknesses from 1-3/8" to 2-1/2" and features a 2-3/4" backset. ANSI/BHMA Series 1000 certified with a 3-hour fire rating, it's engineered for reliability in demanding applications. As an authorized Falcon dealer, E.D. Locks provides expert guidance on keying options, finishes, and installation. Contact our team at sales@edlocks.com or 1-877-207-6067 for personalized support.
Specifications
- Door Thickness: 1-3/8" to 2-1/2"
- Backset: 2-3/4"
- Case: Cold formed steel, zinc dichromate plated, 0.090" thick
- Hubs: Hardened steel
- Cylinders: Solid brass, 5/6/7-pin standard; 6/7-pin I/C
- Latch Bolt: Two-piece stainless steel, 3/4" projection
- Dead Bolt: 1" throw with saw-resistant rollers
- Faceplates: 1-1/4" x 8", brass or stainless steel
- Electrified: 12 or 24 VDC available
- Certification: ANSI/BHMA 156.13 Series 1000, UL 3-hour A label
- Keying: "G" keyway standard; "A" keyway on I/C
- Furnished with two nickel silver keys
