Description
The Falcon TP65E D 606 is a heavy-duty mortise lock built for commercial environments including offices, hospitals, and educational facilities. It features an interchangeable core design for quick re-keying, a mechanical anti-friction latch bolt with a 1-inch throw dead bolt, and saw-resistant rollers. Designed for constant-use applications where reliability is non-negotiable.
This lock accommodates doors 1-3/8" to 2-1/2" thick and is reversible in the field for flexible installation. It's compatible with SFIC products and meets ANSI/BHMA 156.13 Series 1000 standards with a 3-hour UL A label. Contact our team at sales@edlocks.com or 1-877-207-6067 for expert guidance on keying options, finishes, and electrified configurations.
Specifications
- Door thickness: 1-3/8" to 2-1/2"
- Backset: 2-3/4"
- Case: Cold formed steel, zinc dichromate plated, 0.090" thick
- Hubs: Hardened steel
- Cylinders: Solid brass, 5, 6, or 7-pin standard; 6 or 7-pin interchangeable core
- Standard keyways: "G" (standard cylinder), "A" (I/C cylinder)
- Latch bolt: Two-piece stainless steel, 3/4" projection
- Dead bolt: 1" throw stainless steel with 13/16" saw-resistant rollers
- Faceplates: 1-1/4" x 8" brass or stainless steel, adjustable for door bevel
- Electrified: Available 12 or 24 VDC
- Standards: ANSI/BHMA 156.13 Series 1000, UL 3 hour A label, ANSI A115.1
