Description
The Falcon TP65E D 630 is a commercial mortise lock engineered for high-traffic office, hospital, and education environments. This MA Series lock combines dependable security with interchangeable core technology for fast re-keying and retrofit installations, making it ideal for facility managers seeking durable, field-reversible hardware.
The TP65E D 630 accommodates standard door thickness from 1-3/8" to 2-1/2" with a 2-3/4" backset and meets ANSI/BHMA 156.13 Series 1000 and UL 3-hour A-label requirements. Compatible with SFIC cores from other manufacturers, this lock offers 5, 6, or 7-pin cylinders and optional electrified functions. Contact our authorized dealer team at sales@edlocks.com or 1-877-207-6067 for expert keying guidance and configuration support.
Specifications
- Brand: Falcon
- Model: TP65E D 630
- Door Thickness: 1-3/8" to 2-1/2"
- Backset: 2-3/4"
- Case: Cold formed steel, zinc dichromate plated, 0.090" thick
- Hubs: Hardened steel
- Latch Bolt: Two-piece stainless steel, 3/4" projection
- Deadbolt: 1" throw, stainless steel with saw-resistant rollers
- Faceplates: 1-1/4" x 8" brass or stainless steel, adjustable
- Handing: Right hand standard, left hand optional, reversible in field
- Cylinders: 5, 6, or 7-pin available on standard; 6 or 7-pin on interchangeable core
- Keyways: G keyway standard on standard cylinder, A keyway on I/C cylinder
- Electrified Functions: 12 or 24 VDC available
- ANSI/BHMA: 156.13, Series 1000
- UL: 3 hour A label
- Includes: Two nickel silver keys
