Description
The Falcon TP70T A 605 is a commercial mortise lock engineered for high-traffic offices, hospitals, educational institutions, and other demanding environments. Its durable MA Series construction delivers reliable security and smooth operation through years of constant use, with an interchangeable core (IC) cylinder for quick field re-keying without lock removal.
This lock accommodates standard door thickness from 1-3/8" to 2-1/2" with a 2-3/4" backset and meets ANSI/BHMA Series 1000 and 3-hour UL ratings. The IC cylinder is compatible with SFIC products from other manufacturers. For expert assistance selecting the right configuration, keying options, or electrified variants, contact E.D. Locks' authorized sales team at sales@edlocks.com or 1-877-207-6067.
Specifications
- Brand: Falcon
- Model: TP70T A 605
- Door Thickness: 1-3/8" to 2-1/2"
- Backset: 2-3/4"
- Case: Cold formed steel, zinc dichromate plated, 0.090" thick
- Latch Bolt: Two-piece stainless steel, 3/4" projection
- Dead Bolt: 1" throw, stainless steel with saw-resistant rollers
- Cylinders: Solid brass; 5, 6, or 7-pin standard; 6 or 7-pin on IC
- Keyways: G keyway standard (standard cylinder); A keyway standard (IC cylinder)
- Handing: Right hand standard; left hand optional, reversible in field
- Faceplates: 1-1/4" x 8", brass or stainless steel, adjustable for bevel
- Strike: Brass or stainless steel, non-handed, ANSI A115.1 compliant
- Electrified Functions: 12 or 24 VDC available
- Rating: ANSI/BHMA 156.13 Series 1000; UL 3-hour A label
