Description
The Falcon TP70T D 605 is a commercial mortise lock engineered for high-traffic office, hospital, and education environments. This durable MA Series lock combines security with reliability, featuring a two-piece stainless steel latch bolt, anti-friction mechanics, and a 1-inch throw deadbolt with saw-resistant rollers. It solves the need for dependable access control in demanding institutional settings.
The lock accommodates door thickness from 1-3/8" to 2-1/2" with a 2-3/4" backset and includes an interchangeable core for quick re-keying compatible with SFIC products. It meets ANSI/BHMA Series 1000 and carries a 3-hour UL A label. As an authorized Falcon dealer, E.D. Locks provides expert specification guidance and technical support at sales@edlocks.com or 1-877-207-6067 to ensure proper selection and installation.
Specifications
- Brand: Falcon
- Model: TP70T D 605
- Door Thickness: 1-3/8" to 2-1/2"
- Backset: 2-3/4"
- Case: Cold formed steel, zinc dichromate plated, 0.090" thick
- Hubs: Hardened steel
- Cylinders: Solid brass, 5, 6, or 7-pin standard; 6 or 7-pin interchangeable core
- Latch Bolt: Two-piece stainless steel, 3/4" projection
- Deadbolt: 1" throw stainless steel with saw-resistant rollers
- Faceplates: 1-1/4" x 8" brass or stainless steel
- Standard Keyways: "G" on standard cylinder, "A" on I/C cylinder
- Handing: Right hand standard, left hand optional, field reversible
- Electrified: Available 12 or 24 VDC
- Standards: ANSI/BHMA 156.13 Series 1000, UL 3-hour A label
