Description
The Falcon TP70T Q 605 is a commercial mortise lock designed for offices, hospitals, education facilities, and other institutional buildings requiring durable, high-performance security. This MA Series lock combines affordability with reliability, engineered to withstand constant daily use without compromising function or safety for your facility.
The TP70T Q 605 features an interchangeable core (SFIC compatible) for quick re-keying, fits standard door thicknesses from 1-3/8" to 2-1/2", and meets ANSI/BHMA 156.13 Series 1000 and UL 3-hour A label standards. As an authorized Falcon dealer, E.D. Locks offers expert guidance on keying options, electrified functions (12 or 24 VDC), and installation support. Contact sales@edlocks.com or 1-877-207-6067 for technical assistance.
Specifications
- Brand: Falcon
- Model: TP70T Q 605
- Lock Type: Mortise
- Door Thickness: 1-3/8" to 2-1/2"
- Backset: 2-3/4"
- Case: Cold formed steel, zinc dichromate plated, 0.090" thick
- Hubs: Hardened steel
- Handing: Right hand standard; left hand optional, reversible in field
- Cylinders: Solid brass, 5/6/7-pin standard or 6/7-pin interchangeable core
- Keyways: G (standard cylinder), A (interchangeable core)
- Latch Bolt: Two-piece stainless steel, 3/4" projection
- Dead Bolt: 1" throw, stainless steel with saw-resistant rollers
- Faceplates: 1-1/4" x 8" brass or stainless steel, adjustable
- Electrified Functions: 12 or 24 VDC available
- Certifications: ANSI/BHMA 156.13 Series 1000, UL 3-hour A label
- Includes: Two nickel silver keys
