Description
The Falcon TP70T A 625 is a heavy-duty mortise lock built for commercial environments like offices, hospitals, and educational facilities. Featuring a two-piece stainless steel latch bolt and a 1-inch deadbolt with saw-resistant rollers, this lock delivers reliable security and withstands constant daily use without compromise.
Compatible with standard 1-3/8" to 2-1/2" door thicknesses and featuring an interchangeable core (SFIC) for quick re-keying, the TP70T simplifies maintenance and retrofit projects. As an authorized Falcon dealer, E.D. Locks offers expert product guidance and support. Contact our team at sales@edlocks.com or 1-877-207-6067 for compatibility questions or keying assistance.
Specifications
- Door Thickness: 1-3/8" to 2-1/2"
- Backset: 2-3/4"
- Case: Cold formed steel, zinc dichromate plated, 0.090" thick
- Hubs: Hardened steel
- Handing: Right hand standard; left hand optional, reversible in field
- Cylinders: Solid brass, 5/6/7-pin standard or 6/7-pin interchangeable core
- Keyways: G keyway standard; A keyway on I/C cylinder
- Latch Bolt: Two-piece stainless steel, mechanical anti-friction, 3/4" projection
- Deadbolt: 1" throw, stainless steel with hardened steel rollers
- Faceplates: 1-1/4" x 8" brass or stainless steel, adjustable for door bevel
- Strike: Brass or stainless steel, meets ANSI A115.1
- Electrified: Available in 12 or 24 VDC
- Certification: ANSI/BHMA 156.13 Series 1000; UL 3 hour A label
